Products Data Diode Products

Data Diode Products

Comprehensive, hardware-enforced data diode cybersecurity products for commercial and industrial use, built from the ground up for seamless data availability and unhackable security.

Unhackable Network and Digital Asset Security

Owl offers the most flexible line of data diode cybersecurity products available. Customers can choose from the appropriate hardware platform, which includes a base software package, and then select optional add-on software modules (at an additional cost) to meet their solution needs.

Data Diode Products by Form Factor
Rack-Mounted DIN-Rail
Rack-Mounted

Rack-Mounted

Owl rack-mounted data diode products come in all-in-one, standard 19” 1U or 2U form factors and fit comfortably in a standard data center or server room metal rack. Designed to meet a variety of operational needs, these appliances are our most popular solutions for commercial and industrial applications.
  • Multi-purpose/Multiple Streams
  • Standard, mid, and high capacity configurations
  • Compatible w/ all Owl Software Modules
OPDS-1000
Multi-purpose, High Throughput
ReCon 2U
EPDS
Multi-purpose, Very High Throughput
XD Verge
FPGA-based one-way transfer & protocol enforcement
Owl PaciT®
Raw Ethernet Packets, Very High Throughput
XD Matrix
Hardware-enforced data aggregation
XD Prism MPP
Multi-purpose STIG-compliant OWT Solution
SSUS
Compare Products
DIN-Rail

DIN-Rail

The Owl DIN rail data diode product offers convenience and efficiency by being designed vertically, making it the ultimate space-saver. Its durability is optimal for extreme environments or facilities that are exposed to various elements.
  • Includes OPDS-Talon Software Platform
  • Multi-purpose/Multiple Streams
  • Standard and high capacity configurations
  • Designed for Harsh/Industrial Environments
XD Verge
FPGA-based one-way transfer & protocol enforcement
Compare Products
icon
One-Way Security

Owl Data Diode Products are designed to provide deterministic data transfer in only one direction (unidirectional), to segment and protect networks, devices, and other digital assets (databases, historians, SCADA, PLCs, DCS, etc.) from external cyber threats.

icon
Any-Industry Capability

Owl Data Diode Products have been deployed across a wide range of vertical markets, including power plants, banks, train stations, manufacturing plants, substations, hospitals, refineries, oil rigs, and more.

Proprietary Software for Owl Data Diode Products
icon
OPDS Software Platform
OPDS Talon

OPDS Talon

Talon, Owl’s proprietary hardened operating system, provides secure menu-based device administration and application support. Easily configure data flows, protocols, and connections with network endpoints with a simple, intuitive user interface. Talon operates on all OPDS and EPDS devices (excludes SSUS).

KEY FEATURES:

  • Menu-based server configuration
  • Hardened Linux operating system that follows Center for Internet Security (CIS) benchmarks
  • Unsupported IP protocol ports are disabled, restricting traffic before packets can enter the system
  • Common network diagnostics tools available in menu
  • Simplified process for updating and viewing current software versions
  • Application updates for improved performance and stability

Applications and Connectors

icon
Modbus Transfer
MBTS
icon
Performance Management
OPMS
icon
OSIsoft PI System Transfer
OPTS
icon
OPC Transfer
OSTS
icon
Screen Replication
OV2S
icon
Remote File Transfer
RFTS
icon
IEC 104 Transfer
IEC 104
icon
HTTP Transfer
HTTP
icon
MQ Telemetry Transport
MQTT
icon
Application Connector
OPC UA
Product Comparison Chart
Rack-Mounted
OPDS-1000
EPDS
FUNCTIONALITY
Multi-Purpose
Multi-Purpose
CONFIGURATIONS
Standard capacity: 26 Mbps
Mid Capacity: 155 Mbps
High Capacity: 1,000 Mbps
Standard capacity: 1 Gbps
Mid Capacity: 5 Gbps
High Capacity: 10 Gbps
FORM FACTOR
1U Rack Mount
2U Rack Mount
BASE PROTOCOL
SUPPORT
UDP, TCP/IP, SNMP, SMTP, FTP
UDP, NTP, TCP/IP, SNMP, SMTP, FTP
SOFTWARE MODULE
COMPATIBILITY
OSISOFT PI SYSTEM TRANSFEROPTS
OPC TRANSFEROSTS
MODBUS TRANSFERMBTS
SCREEN REPLICATIONOV2S
REMOTE FILE TRANSFERRFTS
LOG FILE TRANSFEROLFS
OWL PERFORMANCE MANAGEMENTOPMS
Download Chart
Tap to Download Our Product Comparison Chart

Want to Learn More About Data Diodes?

Check out our in-depth educational page!

Learn More
