XD Vision*
Multi-domain confidential voice, video teleconferencing (VTC), full motion video (FMV) and structured data (XML) streaming and collaboration across up to 7 or more domains.
*XD Vision was previously known as V3CDS
Multi-Domain Voice & Video Teleconferencing (VTC), Full-Motion Video (FMV), and XML Data Transfer
XD Vision is a multi-domain, scalable, secure software-based cross domain solution for sharing high-definition video and audio among multiple classified or coalition domains. Designed with a base 3-domain architecture, it can support Voice / Video teleconferencing (VTC), full-motion video (FMV), and XML Structured/Fixed Format data transfer between up to 7 or more domains (depending on throughput requirements). XD Vision can be configured as requirements grow to add additional domains, data types, and/or call and stream volume.
KEY FEATURES
Designed for multi-domain collaboration, XD Vision builds off of Owl’s revolutionary voice and video cross domain technology, enabling flexible data sharing and calling across multiple classified and/or coalition networks in real-time. From FMV feeds to video teleconferencing, XD Vision is the world’s most capable multi-domain voice and video cross domain solution.
- Designed for Multi-Domain Voice/VTC, FMV, XML Streaming
- Enables audio, face phone & point-to-point VTC calls between security domains (TS-S, S-S, S-U)1
- Mitigates covert transmission of information over VoIP channels through real-time security filtering and audio processing
- Provides user accountability mechanisms, including monitoring all calls for recording conversations for playback and auditing purposes
- Maintains strict packet handling conformance to industry standards while protecting against protocol exploits
- Supports existing VoIP infrastructures (PBX & endpoints) and Connects to existing Call Managers & MCUs as a SIP Trunk provider
- Scalable, Flexible Configuration with Remote Administration & Monitoring
- In LBSA Testing, Anticipated Completion Q4 2024
XD Vision Components
DISPATCHER:
The Dispatcher verifies domains attempting to exchange data are allowed (based on the Security Policy) and routes the data to an available Pipeline Appliance (PLA).
PIPELINE APPLIANCE (PLA)
The Pipeline Appliance manages the data transfer between domains. Filters the data (based on the Security Policy) and routes it through the Dispatcher to a Gateway on another domain.
GATEWAY SERVER
The Gateway Server contains the Protocol Adapters to accept and connect various data types between domains.
Geofencing Support
XD Vision supports geofencing, a location-based technology that captures and manages global positioning (GPS) coordinates from the KLV metadata for creating blackout regions for FMV sharing by setting virtual perimeters around a geographic boundary. The defined geofenced coordinates can be output so that the eXtensible Stylesheet Language for Transformation (XSLT) filter in the Assured Pipeline appends a redacted tag to any XML file that contains the geographic coordinates that fall within any of the specified regions.
Supported Protocols
- Session Initiation Protocol (SIP)
- Real Time Transport Protocol (RTP)
- Real Time Streaming Protocol (RTSP)
- Transmission Control Protocol (TCP)
- User Datagram Protocol (UDP)
- ISA C2 sensor control protocol
- MPEG-TS, H.263, H.263+, H.264, XML
Technical Specifications (Default Data Center Configuration)
DISPATCHER: HPE ProLiant DL380 Gen10
DIMENSIONS (H x W x D)
- 44.55 x 73.03 x 8.74 cm
- 17.54 x 28.75 x 3.44 in
FORM FACTOR
- 2U rack
PROCESSOR
- Intel® Xeon® Scalable Processor Family
TEMPERATURE
Standard Operating Temperature
- 10° to 35°C (50° to 95°F) at sea level
POWER SUPPLY
- 5918 BTU/hr (at 200 VAC), 5888 BTU/hr (at 220 VAC), 5884 BTU/hr (at 240 VAC)
ALTITUDE
Operating
- 3050 m (10,000 ft)
Non-operating
- 9144 m (30,000 ft)
WEIGHT
Minimum:
- 14.76 kg / 32.54 lb
Maximum:
- 34.12 kg / 75.23 lb
HUMIDITY
Operating
- 8% to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, non-condensing.
Non-operating
- 5 to 95% relative humidity (Rh), 38.7°C (101.7°F)
maximum wet bulb temperature, non-condensing
PLA: HPE ProLiant DL385 Gen 10 Plus v2 (Pre-configured model)
DIMENSIONS (H x W x D)
SFF Drives:
- 8.75 x 44.54 x 71.1 cm
- 3.44 x 17.54 x 28 in
LFF Drives:
- 8.75 x 44.54 x 74.9 cm
- 3.44 x 17.54 x 29.5 in
FORM FACTOR
- 2U rack
PROCESSOR
- AMD® EPYC® 7002 Series Processors
TEMPERATURE
Standard Operating Temperature
- 10° to 35°C (50° to 95°F) at sea level
POWER SUPPLY
For 1400W Power Supply:
- 1400W (at 240 VAC), 1400W (at 240 VAC)
ALTITUDE
Operating
- 3050 m (10,000 ft)
Non-operating
- 9144 m (30,000 ft)
WEIGHT
Minimum:
- 15.1 kg / 33.25 lb
Maximum:
- 24.7 kg / 54.5 lb
HUMIDITY
Operating
- 8% to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, non-condensing.
Non-operating
- 5 to 95% relative humidity (Rh), 38.7°C (101.7°F)
maximum wet bulb temperature, non-condensing
GATEWAY: HPE ProLiant DL360 Gen 10 (x2)
DIMENSIONS (H x W x D)
SFF Drives:
- 4.29 x 43.46 x 70.7 cm
- 1.69 x 17.11 x 27.83 in
LFF Drives:
- 4.29 x 43.46 x 74.98 cm
- 1.69 x 17.11 x 29.5 in
FORM FACTOR
- 1U rack
PROCESSOR
- Intel® Xeon® Scalable Processor Family with up to 28 cores
TEMPERATURE
Standard Operating Temperature
- 10° to 35°C (50° to 95°F) at sea level
POWER SUPPLY
- 5918 BTU/hr (at 200 VAC), 5888 BTU/hr (at 220 VAC), 5884 BTU/hr (at 240 VAC)
ALTITUDE
Operating
- 3050 m (10,000 ft)
Non-operating
- 9144 m (30,000 ft)
WEIGHT
SFF Minimum
- 13.04 kg / 28.74 lb
SFF Maximum
- 16.27 kg / 35.86 lb
LFF Minimum
- 13.77 kg / 30.36 lb
LFF Maximum
- 16.78 kg / 37 lb
HUMIDITY
Operating
- 8% to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, non-condensing.
Non-operating
- 5 to 95% relative humidity (Rh), 38.7°C (101.7°F)
maximum wet bulb temperature, non-condensing
