OPDS-1000

Owl Perimeter Defense Solution - 1000

OPDS-1000 is the most powerful, flexible all-in-one data diode solution on the market today. The 1U rack-mountable platform fits any standard 19″ server rack.

Overview

Powerful Capability

OPDS-1000 supports the secure one-way data transfer of multiple data types and formats concurrently.  Optimized for more demanding industrial control applications, it supports three configurations, including standard capacity (26 Mbps), mid capacity (155 Mbps), and high capacity (1,000 Mbps).  The integrated, EAL4+ certified Owl communication cards form a deterministic one way link with an absolute protocol break, ensuring the highest level of security available.

Extensive Applications

Supporting a broad range of applications (sensor data, data points from real-time database historians, etc.) it protects critical infrastructure from escalating external threats while enabling the transfer of business-critical data from the industrial control network to the business network.

High Availability

For organizations who cannot risk downtime, the OPDS High Availability Solution (OPDS-HA) can provide 24/7/365 protection and communications. When access to data is mission critical, the OPDS-HA solution can maximize uptime and ensure that data never stops flowing during a hardware or network outage. OPDS-HA consists of a pair of OPDS data diodes to create a high availability solution and provides unmatched flexible protocol and datatype support.



Learn More

Supported Protocols

Supported Protocols

Natively supports UDP, TCP/IP, SNMP, SMTP, NTP, SFTP and FTP transfers (separately or simultaneously)

Tech Specs

Technical Specifications

OPERATING CONDITIONS:

32°F to +110°F

0°C to +43.33°C

5% to 90% humidity non-condensing

POWER SUPPLY:

Input: 75-230 VAC,

Estimated Normal operating Usage 10-16 W/side

Max. 20W per side

STORAGE:

-40°F to 158°F

-40°C to 70°C

5% to 90% humidity non-condensing

VIBRATION:

Vibration: (IEC 60255-21-1)

Vibration 1g(10-500Hz) (Operational)

Vibration 2g(10-500Hz) (Operational and Non-Operational)

CHASSIS:

Black Anodized aluminum with Locking Top

MOUNTING SYSTEM:

(1U) Rack Mount, tabletop

NETWORK CONNECTIVITY:

1000 base-T copper

Separate Ethernet connections for network traffic and remote administration

Physical connectors: 8P8C (RJ45)



THROUGHPUT:

Supports three configurations: standard capacity (26 Mbps), mid capacity (155 Mbps), and high capacity (1,000 Mbps)



SHOCK:

Shock: (IEC 60255-21-2)

Shock 10g 11ms (Operational)

Shock 30g 11ms (Operational and Non-Operational)

COOLING:

Conductive cooling through enclosure side walls with High Life Expectancy/Low Noise Fans

APPROVALS:

FCC Class A compliance

CE Mark

CB Certificate: DE 2-034658

EN 62368-1:2014/AC:2015

International Common Criteria Certification – EAL4+ Certified

VCCI

ISO:

Manufactured using ISO 9001:2015 certified quality program



CHASSIS SIZE:

16.5” W x 1.75” H x 13” D

41.91 cm x 4.5 cm x 33 cm



UNIT WEIGHT:

7.92 lbs./3.6 kg.

MEAN TIME BETWEEN FAILURE (MTBF):

11+ years

LOCAL ADMINISTRATION:

VGA connector for monitor

USB connectors for keyboard and mouse
