The OCDS-ST06 is Owl’s accredited, hardware-enforced one-way transfer solution for full-motion video (FMV) and sensor data streaming.
Accredited. Proven. Secure.
In the tactical theatre, video and other UDP-based intelligence data is often accumulated in unclassified environments (sensors, vehicles, UAVs, vessels). To reach classified-level analysts, the data must securely cross network domain boundaries. This requires a proven, high-bandwidth Cross Domain Solution (CDS) that transfers streaming full-motion video and metadata at real-time from the field to secure enclaves.
The OCDS-ST06 moves UDP packets containing MPEG-TS video from Unclassified to Secret network domains with minimal latency and without data loss. Tested in deployment and fully operational, the OCDS-ST06 is NCDSMO baseline-listed and received ATO (Authorization to Operate) on February, 2015. The OCDS-ST06 presents a configurable number of UDP inlet sockets to the source network. UDP payload content is restricted to MPEG-TS packets containing full-motion video and KLV metadata. The Owl MPEG data filters explicitly check MPEG-TS packet framing, MPEG-TS protocol, and KLV metadata conformance to MISB standards.
Key Features
The CDS-ST06 software is based on a STIG compliant, CLIP and SELinux enforced, EAL4+ Red Hat Enterprise Linux (RHEL) foundation. It’s capable of UDP, MPEG-TS, and KLF filtering to ensure only authorized content is transferred by the data flows. The OCDS-1000 is a dual-node platform that includes two processing environments separated by Owl’s patented hardware-enforced, one-way transfer diodes. These combined technologies provide dataflow protection for the highest threat environment connections.
- Latency -3ms to 8ms depending on filter
- UDP-based FMV and data streaming
- UDP data flow types: Filtered UDP unicast, multicast streams, UDP broadcast
- UDP Sockets
What’s Included:
Hardware
- OCDS-1000 Platform
- 2 1U Server Mounting Ear Brakets
- 4 1U Ear Braket Screws
- DVD Power Supply (For Blue Side Only)
- DVD/CD RW Reader (For Blue Side Only)
- USB to [A-B] Type (Blue)
- DVD Power Supply (For Red Side Only)
- DVD/CD RW Reader (For Red Side Only)
- USB to [A-B] Type (Red)
- 2 15′ Ethernet Cable (Blue)
- 2 15′ Ethernet Cable (Red)
Software
- Documentation Disc
- Red Side Installation Media
- Blue Side Installation Media
- RFTS SCAN Red Software
- RFTS SCAN Blue Software
Technical Specifications
OPERATING CONDITIONS
32°F to 110°F (0°C to 43.33°C) – 20% to 85% humidity non-condensing
POWER SUPPLY
Input: 100-240V AC auto-ranging, min. 30W per side (fused at 1A at IEC connector)
Output: 5V at 5A
EU & UK power cables available upon request
POWER CONSUMPTION
BLUE Inlet Send-only side: 20W Max / 17.6W Nominal / 5.5W Standby
RED Outlet Receive-only side: 20W Max / 17.5W Nominal / 5.5W Standby
STORAGE
-40°F to 158°F (-40°C to 70°C) – 5% to 95% humidity non-condensing
SAFETY STANDARDS
UL60950-1, TUV EN60950-1 approved
TRANSPORT TESTING
Random Vibration and Loose Cargo Transportation Tests — MIL-STD-810F
CHASSIS
Black anodized aluminum
COOLING SYSTEM
High-efficiency fan system with low system acoustic noise level
CHASSIS SIZE
16.5” W x 1.75” H x 13” D (41.91 cm W x 4.5 cm H x 33 cm D)
UNIT WEIGHT
7.92 lbs (3.6 kg)
SHIPPING SIZE
18” W x 8.5” H x 15” D (45.7 cm W x 21.6 cm H x 38.1 cm D)
SHIPPING WEIGHT
12.2 lbs (5.5 kg)
* Solution includes two DVD drives (with power supplies and network cables) for use with software updates and backups
