OCDS-MPP
Owl Cross Domain Solution - Multi Protocol Platform

The OCDS-MPP, Owl’s entry level hardware-enforced one-way transfer enterprise solution is for customers requiring both streaming and file transfer capabilities with environment-constrained data centers.

Overview

It combines Owl’s 1U all-in-one dual processing OCDS-1000 hardware platform and Owl’s Multi-Protocol Platform (MPP) CDS software platform. Owl’s CDS-MPP software is designed to address RTB Composed COTS (CCOTS) CDS design pattern.  The Owl OCDS-1000 hardware platform is reduced Size, Weight, and Power (SWAP) for environmental-constrained data centers. This dual-node platform’s two processing environments are separated by Owl’s patented hardware-enforced, one-way transfer diodes. that support dataflow bandwidth from 26 Mbps to 1 Gbps for UDP and TCP content streaming and file transfers. Bandwidth rates are license upgradeable.



Key Features

The CDS-MPP software is based on a STIG compliant, CLIP enforced, EAL4+ Red Hat Enterprise Linux (RHEL) foundation.  It’s capable of scanning and file validation filtering to ensure only authorized content is transferred by the dataflows. The OCDS-1000 is a dual-node platform that includes two processing environments separated by Owl’s patented hardware-enforced, one-way transfer diodes. These combined technologies provide dataflow protection for the highest threat environment connections.

  • Latency -3ms to 8ms depending on filter
  • UDP-based data streaming and TCP-based file transfers or data streams
  • Up to four dataflow types: Filtered files, non-filtered TCP streams, Filtered UDP unicast and multicast streams, UDP broadcast
  • RFTS, FTP, TCP/UDP Sockets, SFTP
What's Included

What’s Included:

Hardware

  • OCDS-1000 Platform
  • Two 1U Server Mounting Ear Brakets
  • Four 1U Ear Braket Screws
  • DVD Power Supply (For Blue Side Only)
  • DVD/CD RW Reader (For Blue Side Only)
  • USB to [A-B] Type (Blue)
  • DVD Power Supply (For Red Side Only)
  • DVD/CD RW Reader (For Red Side Only)
  • USB to [A-B] Type (Red)
  • Two 15′ Ethernet Cable (Blue)
  • Two 15′ Ethernet Cable (Red)

Software

  • Documentation Disc
  • Red Side Installation Media
  • Blue Side Installation Media
  • RFTS SCAN Red Software
  • RFTS SCAN Blue Software



Tech Specs

Technical Specifications

OPERATING CONDITIONS

32°F to +110°F

0°C to +43.33°C

5% to 90% humidity non-condensing





POWER SUPPLY

Input: 75-230 VAC,

Estimated Normal Operating Usage: 10-16W/side

Max. 20W per side



STORAGE

-40°F to 158°F

-40°C to 70°C

5% to 90% humidity non-condensing



VIBRATION

Vibration: (IEC 60255-21-1)

Vibration 1g (10-500Hz) (Operational)

Vibration 2g (10-500Hz) (Operational and Non-Operational)

CHASSIS

Black Anodized aluminum with Locking Top



MOUNTING SYSTEM

(1U) Rack Mount



NETWORK CONNECTIVITY

Separate Ethernet connections for network trac and independent configurations

Physical connectors: 8P8C (RJ45)

Supports bandwidth rates of: 26 Mbps, 52 Mbps, 104 Mbps, 155 Mbps, 300 Mbps, 600 Mbps, 1000 Mbps (1 Gbps)



COOLING SYSTEM

Conductive cooling through enclosure side walls with High Life Expectancy/Low Noise Fans

APPROVALS

FCC Class A compliance
CE Mark
CB Certificate: 72161659
UL 60950-1:2007 R10.14
CAN/CSA-C22.2 NO.60950-1-07+A1:2011+A2:2014

International Common Criteria Certification – EAL Certified



ISO

Manufactured using ISO9001:2015 certified quality program

Chassis Size & Unit Weight:

16.5” W x 1.75” H x 13” D

41.91 cm x 4.5 cm x 33 cm

7.92 lbs./3.6 kg.



MEAN TIME BETWEEN FAILURE (MTBF)

11+ years



LOCAL ADMINISTRATION

VGA connector for monitor

USB connectors for keyboard and mouse
