OCDS-FT15
Owl Cross Domain Solution - File Transfer

The OCDS-FT15, Owl’s accredited entry level and accredited hardware-enforced one-way transfer enterprise solution is for customers requiring file transfers.

Overview

Secure, Deterministic Cross Domain File Transfer

It combines Owl’s 1U all-in-one dual processing node OCDS-1000 hardware platform and Owl’s File Transfer (FT15) software that is designed to address RTB Composed COTS (CCOTS) CDS design pattern. The Owl OCDS-1000 hardware platform is reduced Size, Weight, and Power (SWAP) for environmental-constrained data centers. This dual-node platform’s two processing environments are separated by Owl’s patented hardware-enforced, one-way transfer diodes. that support dataflow bandwidth from 26 Mbps to 1 Gbps for file transfers. Bandwidth rates are license upgradeable.

The OCDS-FT15 is a certified and accredited Cross Domain Solution as a Tailored Variant of OCDS-FT01; it is operational and serving DoD missions.  It was designed as a one-way data transfer solution moving files from Unclassified domains to Top Secret networks. Unlike FT01 which is deployed on two separate enterprise servers, FT15 is packaged in the Owl 1U rackmount enclosure.  The 1U enclosure includes two independent servers separated by our proprietary data diode-based technology.

Key Features

The OCDS-FT15 software is based on a STIG compliant, CLIP enforced, EAL4+ Red Hat Enterprise Linux (RHEL) foundation.  It’s capable of scanning and file validation filtering to ensure only authorized content is transferred by the dataflows. The OCDS-1000 is a dual-node platform that includes two processing environments separated by Owl’s patented hardware-enforced, one-way transfer diodes. These combined technologies provide dataflow protection for the highest threat environment connections.

  • TCP-based file transfers
  • Supports up to 71 file types with file type checking
  • ASCII checks and other filters
  • RFTS, FTP, SFTP
What's Included

What’s Included:

Hardware

  • OCDS-1000 Platform
  • Two 1U Server Mounting Ear Brakets
  • Four 1U Ear Braket Screws 4
  • DVD Power Supply (For Blue Side Only)
  • DVD/CD RW Reader (For Blue Side Only)
  • USB to [A-B] Type (Blue)
  • DVD Power Supply (For Red Side Only)
  • DVD/CD RW Reader (For Red Side Only)
  • USB to [A-B] Type (Red)
  • Two 15′ Ethernet Cable (Blue)
  • Two 15′ Ethernet Cable (Red)

Software

  • Documentation Disc
  • Red Side Installation Media
  • Blue Side Installation Media
  • RFTS SCAN Red Software
  • RFTS SCAN Blue Software
Tech Specs

Technical Specifications

OPERATING CONDITIONS

32°F to 110°F (0°C to 43.33°C) – 20% to 85% humidity non-condensing



POWER SUPPLY

Input: 100-240V AC auto-ranging, min. 30W per side (fused at 1A at IEC connector)

Output: 5V at 5A

EU & UK power cables available upon request



POWER CONSUMPTION

BLUE Inlet Send-only side: 20W Max / 17.6W Nominal / 5.5W Standby

RED Outlet Receive-only side: 20W Max / 17.5W Nominal / 5.5W Standby

STORAGE

-40°F to 158°F (-40°C to 70°C)

– 5% to 95% humidity non-condensing



SAFETY STANDARDS

UL60950-1, TUV EN60950-1 approved



POWER CONSUMPTION

Random Vibration and Loose Cargo Transportation Tests — MIL-STD-810F



CHASSIS

Black anodized aluminum



COOLING SYSTEM

High-efficiency fan system with low system acoustic noise level

CHASSIS SIZE

16.5” W x 1.75” H x 13” D

(41.91 cm W x 4.5 cm H x 33 cm D)



UNIT WEIGHT

7.92 lbs (3.6 kg)



SHIPPING SIZE

18” W x 8.5” H x 15” D

(45.7 cm W x 21.6 cm H x 38.1 cm D)



SHIPPING WEIGHT

12.2 lbs (5.5 kg)
